Revolutionizing Chip Design in the Cloud

Cadence OnCloud Managed Cloud Service

In today's fast-paced semiconductor industry, engineering teams are under pressure to deliver complex designs in a compressed timeframe. Traditional on-premises infrastructure often struggles to keep up with the compute demands of modern EDA workflows. Enter EDA in the cloud, which is reshaping how chips are designed, verified, and implemented. This solution can work for all in-the-cloud or peak/burst use-cases.

What Is Cloud EDA?

Cloud EDA refers to using cloud-based platforms to run EDA tools and workflows. Instead of relying on local servers and IT/CAD teams to manage compute resources, design teams can access scalable, secure, and turnkey environments in the cloud. This shift enables faster setup, seamless collaboration, and significant cost savings.

Top 3 Reasons to use Cadence OnCloud: The Leading EDA Cloud Platform

Cadence's Managed Cloud Service, part of the Cadence OnCloud portfolio, is a production-proven, EDA-optimized platform designed to jump-start chip design projects with minimal IT overhead. Whether you're working on analog simulation, digital implementation, or physical verification, Cadence offers a full front-to-back design flow in the cloud, boasting these features:

• Productivity Boost: Up to 25X faster setup and 5X turnaround time (TAT) improvements.

• Security First: ISO/IEC 27001/27017 and SOC 2 certified, with encrypted data in transit and at rest. Fully approved by leading foundries.

• Cost Efficiency: Scale based on project needs without upfront investment.

Ready to Experience the Future?

Explore the Cadence Managed Cloud Service and sign up for a free trial today to see how EDA cloud can transform your design workflow.
