Faster Standard Cell Layout: Auto Place and Route with Virtuoso Layout Suite MXL

Are you still manually placing and routing standard cells, spending hours on repetitive tasks, and risking design inconsistencies? The VLANT4 Training Byte is here to change that.

The Challenge

Standard cell layout design at advanced nodes demands precision, speed, and compliance with complex design rules. Manual layout methods often fall short, leading to longer design cycles and increased risk of errors.

The Solution

The VLANT4_IC 23.1 course, Auto Place and Route (APR) for Virtuoso Studio – Standard Cell, offers a guided, automated flow that simplifies layout creation while ensuring constraint compliance. This Training Byte is now available in the Cadence ASK Portal and is designed to help layout engineers transition from manual to automated workflows.

What You’ll Learn

VLANT4 walks you through the complete APR flow:

• Workspace Setup: Define Width Spacing Patterns (WSPs), row regions, and supply grids
• Placement Automation: Use the Auto P&R Assistant to place standard cells, tap cells, and filler cells
• Routing Automation: Leverage the Routing Assistant to generate LVS/DRC-compliant routing
• Result Analysis: Review layout quality using the Routing Results Browser (RRB)

The course includes interactive labs and quizzes to reinforce learning.

Why It Matters

Virtuoso APR enables:

• Constraint-compliant and DRC-clean layouts
• Faster design cycles with early parasitic extraction
• Scalable automation for exploratory and production-level designs

Virtuoso APR optimizes integrated circuit (IC) design by automating placement, routing, and analytical processes, enabling engineers to produce constraint-compliant layouts efficiently and reliably. The course incorporates practical laboratory exercises and assessments to provide comprehensive proficiency with the tools essential for effective and scalable semiconductor design.

Discover the key terms in Virtuoso APR for standard cell placement

In this video, we examine the terms used in Virtuoso APR for standard cell placement. You will learn how boundary cells prevent electrical effects, tap cells reduce latch-up effects, and filler cells ensure design compliance.

Virtuoso Automated Standard Cell Placement and Routing Flow

In this video, you’ll learn the Virtuoso Automated Standard Cell Placement and Routing Flow. It covers the standard cell placement and routing process in Virtuoso, including setup, placement, routing, and a detailed breakdown of each step.

What is Standard Cell APR Placement

In this video, you will learn about Standard Cell APR Placement in the Virtuoso environment, wire length, and performance by automatically placing standard cells on the silicon die.

What Is Automated Standard Cell Routing?

In this video, you will learn about Automated Standard Cell Routing in the Virtuoso environment, which leverages Innovus NanoRoute router for optimized routing, starting with schematic-driven layout generation, and streamlining APR processes.

To learn quickly about this APR flow, explore the short training bytes in this channel: Auto Place and Route (APR) for Virtuoso Studio – Standard Cell vIC 23.1

Enroll in the Course Auto Place and Route (APR) for Virtuoso Studio – Standard Cell to learn more about Automated Place and Route in Virtuoso Studio.
