Clear silkscreen from pins in Allegro Package

chads108
chads108 over 13 years ago

 Does anyone have some SKILL code that will clear silkscreen lines back x distance from pins, either as a group or individually?  I want to use this during footprint building.  Currently I have to use delete and cut to remove pieces of lines that run through pads.

  • Sign in to reply
  • Cancel
  • oldmouldy
    0 oldmouldy over 13 years ago
    Surely, when designing the symbol, you don't draw the silkscreen over the pins anyway??
    • Cancel
    • Vote Up +1 Vote Down
    • Sign in to reply
    • Verify Answer
    • Cancel
  • chads108
    0 chads108 over 13 years ago
    Not typically, but sometimes it is easier to draw a simple rectangle, place it and then delete what I don't want.  We also use LP Wizard to build footprints and it will sometimes create the silkscreen over the pads which means a little clean-up on our part.
    • Cancel
    • Vote Up +1 Vote Down
    • Sign in to reply
    • Verify Answer
    • Cancel
  • eDave
    0 eDave over 13 years ago
    I have a silkscreen outline routine that traces the assembly outline and clears the pads. It needs some work before I can post it but, if it's what you want, I'll look at it.
    • Cancel
    • Vote Up +1 Vote Down
    • Sign in to reply
    • Verify Answer
    • Cancel
  • chads108
    0 chads108 over 13 years ago

     Thank you for the offer, but our silkscreen rarely follows the assembly outline.  For us, the assembly outline is at maximum tolerance and the silkscreen is at median tolerance condition.  I think from our standpoint, having a routine that will delete the silkscreen line back some default distance from the pad, or mask edge, of a pin, or pins, would make the most sense.  Thank you anyway.

    • Cancel
    • Vote Up +1 Vote Down
    • Sign in to reply
    • Verify Answer
    • Cancel
  • eDave
    0 eDave over 13 years ago
    OK.My routine can be modified to look at the existing silkscreen instead of the outline. I'll look at it today.
    • Cancel
    • Vote Up +1 Vote Down
    • Sign in to reply
    • Verify Answer
    • Cancel
>
